VISION ENGINEERING XPRESS

VISION ENGINEERING XPRESS thumbnail
VISION ENGINEERING XPRESS thumbnail

Vision Engineering Xpress delivers ultra-fast, accurate 2D measurement within the field of view (FOV), at the touch of a button. It is able to instantly and accurately measure hundreds of features within the field of view in seconds. Vision Engineering Xpress is ideal for customers who require the fastest, simplest way to accurately measure their component parts. Vision Engineering Xpress is ideally suited to profile measurement of small, flat components such as pressed parts, O-rings, low density circuit boards and flexible circuits, as well as thin parts, including bottle tops, small medical devices, and housings. The telecentric lens provides a…

Read more

Contact us for more information :

+62 21 62 63 851 / 52
marketing@yakinmaju.com

Vision Engineering Xpress delivers ultra-fast, accurate 2D measurement within the field of view (FOV), at the touch of a button. It is able to instantly and accurately measure hundreds of features within the field of view in seconds. Vision Engineering Xpress is ideal for customers who require the fastest, simplest way to accurately measure their component parts.

Vision Engineering Xpress is ideally suited to profile measurement of small, flat components such as pressed parts, O-rings, low density circuit boards and flexible circuits, as well as thin parts, including bottle tops, small medical devices, and housings. The telecentric lens provides a completely flat image, across the full field of view, without any curvature or distortion, so you can make highly accurate 2D measurements within the field of view, without having to move the sample.

Vision Engineering Xpress features:

  • Rapid, high accuracy 2D measurement system, within the field of view (FOV).
  • No need for focus adjustment or sample positioning.
  • Reduces measurement time – significantly.
  • Exceptional ease of use – eliminates operator variances.
  • Go, No Go results, with full geometric tolerancing.
  • Operator training takes minutes, not hours.
