WIDIA Cylindrical Victory™ VSM490-15 Series

WIDIA Indexable Milling/90° Shoulder Mills/VSM490-15 Series/Tool Bodies/Metric/VSM490 • Cylindrical End Mills

Since 1929, WIDIA is a company of German origin which innovate tungsten carbide application on cutting-tools. WIDIA holds the world’s first patent for coating indexable inserts, taps and mills with coated grades. Widia devices High-Performance tooling system for robust accuracy tapping on work-piece made of cast iron, solid steel and stainless steel.

The WIDIA Victory™ Shoulder Mills VSM490-15 Series are optimized for versatile use on high-performance milling such as working with solids for face milling, square end on slotting and shoulder milling. The plain shank itself designed to withstand lesser vibration with through coolant to increase precision and uniformity on each cut.

WIDIA Cylindrical Victory™ VSM490-15 Series Features:

• Superior wall and surface finish capabilities.
• “Stepless” solution. True 90° to run precise applications in multiple axial passes.
• Strong concept to run up to 15mm (.590″) depth of cut.
• Effective internal coolant feature, reaching the cutting edge precisely.

To serve your interest on Widia products, kindly contact our Sales Department
