D'ANDREA - Modul Cut MCD' Adapter DIN 69893

D'Andrea MCD’ Turning Tool Holder is devised for heavy-duty application of medium and large sized numerical control (NC) machining especially for lathe turning of internal and external grooving and threading. D'Andrea MCD’ Turning Tool includes toolholders which permit the mounting of tools for internal, external, cutting and threading of the various standard programs on the market. D'Andrea MCD’ Turning Tool Holder Adapter is built according to ISO 26623-1 PSC and HSK-T63 standards with recommended DIN 69893-T, ICTM constructive tolerances (ISO 12164-3) for the application on spindles of MULTI-TASK machinery.

The D'Andrea MCD’ Turning Tool Holder Adapter have 5 different models to choose from. Depend on your application, each line up is composed of toolholders which are interchangeable and made of high quality material for lowest vibration and avoiding chatter. D'Andrea MCD' is highly regarded by fabricator of valve and gas tube making, civil engineering and many more.

D'Andrea Modul Cut Turning Tool Holder Adapter MCD' Features:

• Built in various models from Ø of Minimum 25 mm and Maximum 98 mm, with lenght Minimum 115 mm and Maximum 135 mm.

• Versatile application for turning, cylindrical and conical boring, facing, threading, corner turning, and spherical operations.

• Auto or manually set up using a flange for fastening with a cam lock quick coupling, or automatically with a palletized system and special connectors.

To serve your interest on D'Andrea products, kindly contact our Sales Department
