SHIMPO Cap Torque Testing Unit TNX Series + DSP-10

Nidec-Shimpo Corporation was built to contribute to the development of society and welfare of the general public all over the world by supplying highest quality products in sincere and enthusiastic dedication to the trinity of technology. One of the products offered by the company is Motorized Torque Test Machines - Shimpo TNX Series + DSP-10.

Shimpo DSP-10, combined with Shimpo TNX Series, is devised to semi-automatically measure opening torques of caps, lids, and screws of various containers, such as cosmetics, medical products, and beverages, as well as the tightening force of valves. It uses a servo motor and measures per-angle torque at a constant rotation speed to remove measurement data variation as well as enable more advanced tests and management. Furthermore, this unit is equipped with specialized software called "TNT_DSP" as standard. It can set the test rotation speed and angles, import torque and angle data, and display torque and angle or torque and time in graphical form.

To serve your interest on Shimpo solutions, kindly contact our Sales Department
