Sylvac D300S V2 is devised to streamlining your multiple combination of gauging and up to 8 channel inputs into a single display for better working environment and improved process management. Sylvac D300S V2 is designed with compact form factor and Bluetooth SMART® connectivity to give you the versatility on either table top or panel mounting application. The aluminium enclosure is lightweight and IP40 certified.
By investing on Sylvac D300S V2, you can have much higher efficiency for monitoring, controlling of pass/fail inspection process and lower cost to operates at full potential. Sylvac D300S V2 is highly compatible with many type of gauging probe from various maker. You can use multiple probe combinations which are simultaneously displayed on screen. Its user friendly interface is also supported by high resolution touch screen operation for intuitive application and direct configuration towards PC.
Sylvac Digital Display D300S V2 features:
- Digital display with 8.5’’ touchscreen
- Available in 3 versions:
- 6 USB and M-Bus
- 6 USB and 2 Sylvac capacitive probe input
- 6 USB and 4 Sylvac capacitive probe input
- Automatic detection of connected instruments
- New CPU unit (5 times faster that previous version)
- OS based on Windows 7 embedded
- Display and page setting fully configurable (up to 8 channels per page, up to 64 pages)
- Memorizing of setups and values
- RJ-45 Ethernet connector
- General or individual Preset
- Math functions for each channel
- Numeric, analog and statistic display
- Compatible with Bluetooth SMART® instruments (USB dongle is required)
To serve your interest on various Sylvac solutions, kindly contact our Sales Department
Sylvac Digital Display D300S V2
