Sylvac PS17 Entre-portée is devised as a versatile micro-meter in measuring external diameter, concentricity, gearing pitch, micro thread, and many more. The measuring value of this PS17 bench will be displayed either by a dial gauge or by a digital display unit. Thanks to its user friendly design, you can have faster rates of inspection.
Depends on model, Sylvac PS17 Entre-portée is designed to check dimensions up to 37 mm. These bench tables can be equipped standard Sylvac anvils or Cary type anvils. An adjustable tailstock, as well as many other features and accessories make these tables a must for your workshop or your inspection room. Compared to micrometer, Sylvac PS17 Entre-portée is highly suitable for quality inspection on small precision workpiece such as small fastener, mechanical devices as in medical, sensor, and electronics industry.
Sylvac Bench Table PS17 Entre-portée features:
- Measuring bench with great flexibility of use for external dimensions
- Tailstock adjustable in X axis and in Z
- Mini indicator to display the position in Z axis (height) of the tailstock
- Delivered with carbide anvils 0.7mm with 90°V for the measure of distance width
- Accurate micrometer screw for pre-positioning
- Compatibility with Sylvac anvils (Ø1.5mm) and Cary type anvils
- Several accessories available
- 2 models : integrated P10 capacitive probe (VP) or Ø 8mm bore to locate any other measuring devices (VS)
