SYLVAC External Micrometer S_Mike PRO - Special Anvils IP67

Sylvac External Micrometer S_Mike Pro – Special Anvils IP67 series are optimized for specific application with disk-shaped, spherical and one point spherical for measuring rounded workpieces or various odd shapes which were previously difficult interpoate exactly. Sylvac External Micrometer S_Mike Pro – Special Anvils IP67 has a measuring range from 0mm to 30mm with quick displacement of the measuring spindle 10 mm / rotation.

Features :

• Automatic wake-up by moving the measuring spindle (System Absolu SIS)
• Sleeping mode after 20 min. of no use (System Absolu SIS)
• Position memorized in sleeping mode (System Absolu SIS)
• Water protected for heavy-duty work with coolants and lubricants, protection rating IP67
• Repeatability and reproducibility never reached before
• Thimble in polyacetal-copolymer

Benefits :

• Measuring external diameter, smaller pins, precision tool-making, drills, cavities, plugs, thinner foils, mechatronics and general engineering.
