The Sylvac Digital Protractor are devised by Sylvac SA., to gives the operator access to a multitude of useful functions within an easy to use format. The Sylvac Protractor S239 instruments are equipped with easy to read display and the Sylvac typical of strudily built to withstand indoor and outdoor environment.
The Sylvac Digital Protractor are commonly used in steel construction engineering, tool making fabrication, cabinets, and quality control of finished built. The Sylvac Protractor S239 are also equipped with data connection cable for ease of data record on the computer.
Sylvac Protractor S239 Features:
- Measuring range 1x360°, 2x180°, 4x90°
- Mechanical parts in stainless steel
- Large 8.5mm LCD digits for ease of viewing.
- Zero setting is made against a fixed stop and internal angles from 40º to 160º inclusive can be measured.
- Accessories include an acute angle attachment and a support stand for vertical applications.
- Read-out
• 1 minute of arc or 0.01 degrees of arc
• For accurate settings the instrument is fitted with a micro-fine adjustment
- Accuracy
• 4 minutes of arc
- Range
• With the aid of a push button the range can be selected according to the application. i.e 1 x 360º, 2 x 180º or 4 x 90º. Changing from reading of arc minutes to decimal indication by pressing a button. Example: Angle reading 35º30’ changes to 35.50º
To serve your interest on various Sylvac solutions, kindly contact our Sales Department
Sylvac Protractor S239
To serve your interest on various Sylvac solutions, kindly contact our Sales Department
Request A Quote
To receive further information on SYLVAC PROTRACTOR S239, please complete the following form. We will reply as soon as possible
Sorry, this product does not have video.
