WIDIA Victory™ Shoulder Mills VSM11 Starter Kits

Since 1929, WIDIA is a company of German origin which innovate tungsten carbide application on cutting-tools. WIDIA holds the world’s first patent for coating indexable inserts, taps and mills with coated grades. Widia devices High-Performance tooling system for robust accuracy tapping on work-piece made of cast iron, solid steel and stainless steel.

The WIDIA Victory™ Shoulder Mills VSM11 Series are optimized for versatile use on high-performance milling such as working with solids for face milling, square end on slotting and shoulder milling. The plain shank itself designed to withstand lesser vibration with through coolant to increase precision and uniformity on each cut.

VSM11 is versatile. It is designed:

• specifically for higher productivity seen in most job shops.
• for reduced horsepower at the machine
• for higher speed and feed rates to get jobs done faster

Why you'll like the VSM11:

• cutter bodies have an integral chip gash design for excellent chip evacuation
• one cutter can do 90° shoulder milling, full slotting, 3D pocket milling, circular contour milling ID and OD, helical interpolation and ramping into full material
• hardened-steel construction and hardened pocket seats for improved resistance to deformation
• available in shell, screw on, cylindrical shank, and Weldon shank models with internal air and coolant capability
• reduced cutting forces and improved free-cutting action for a drastic increase in tool life hours

An excellent milling cutter needs an even better insert. The VSM11 11mm insert:

• has an optimized cutting edge and positive rake face that provides a true 90° wall
• reduces cutting forces and provides excellent, stepless surface finishes
•  is available in six WIDIA Victory grades and five geometries

To serve your interest on Widia products, kindly contact our Sales Department
