SYLVAC Micro Bench Table Measurement PS17 VS VP

SYLVAC Micro Bench Table Measurement PS17 VS VP thumbnail

Sylvac PS17 VS/VP is devised as a versatile micro-meter in measuring external diameter, concentricity, gearing pitch, micro thread, and many more. The measuring value of this PS17 bench will be displayed either by a dial gauge or by a digital display unit. Thanks to its user friendly design, you can have faster rates of inspection. Sylvac PS17 VS/VP can also be equipped with x,y,z stage to mount the specimen accurately. Depends on model, Sylvac PS17 VS/VP is designed to check dimensions up to 37 mm. These bench tables can be equipped standard Sylvac anvils or Cary type anvils. An adjustable tailstock, as well…

Read more

Contact us for more information :

+62 21 62 63 851 / 52
marketing@yakinmaju.com

Sylvac PS17 VS/VP is devised as a versatile micro-meter in measuring external diameter, concentricity, gearing pitch, micro thread, and many more. The measuring value of this PS17 bench will be displayed either by a dial gauge or by a digital display unit. Thanks to its user friendly design, you can have faster rates of inspection. Sylvac PS17 VS/VP can also be equipped with x,y,z stage to mount the specimen accurately.

Depends on model, Sylvac PS17 VS/VP is designed to check dimensions up to 37 mm. These bench tables can be equipped standard Sylvac anvils or Cary type anvils. An adjustable tailstock, as well as many other features and accessories make these tables a must for your workshop or your inspection room. Compared to micrometer, Sylvac PS17 VS/VP is highly suitable for quality inspection on small precision workpiece such as small fastener, mechanical devices as in medical, sensor, and electronics industry.

Sylvac Bench Table PS17 VS/VP features:

  • Measuring bench with great flexibility of use for external dimensions
  • Tailstock adjustable in X axis (and in Z, depends on model)
  • Accurate micrometer screw for pre-positioning
  • Compatibility with Sylvac anvils (Ø1.5mm) and Cary type anvils
  • Several accessories available
  • 2 models : Integrated P10 capacitive probe (VP) or free use with indicator (VS)



To serve your interest on various Sylvac solutions, kindly contact our Sales Department

Sylvac Bench Table PS17 VS/VP



To serve your interest on various Sylvac solutions, kindly contact our Sales Department
